Poultry Feed Mixer Mill Grinder Feed Processing Machine
Feed grinder and mixer our company's best-selling feed processing
product. With small footprint and high productivity, it is widely
applicable to large, medium and small farming enterprises. The
equipment consists of two important parts: a grinderand a mixer,
which can quickly grinder materials to a rational level, and evenly
mix and process them into feed. There is no dust in the production
process, the noise is low, and continuous production can be
realized. There is no dust in the production process, the noise is
low, and continuous production can be realized.
1. Grinder part: there are high-speed rotating blades inside. When
the raw material enters the pulverizer, the blade rotates quickly
to pulverize it to the desired fineness, and then sieves it out
through the sieve.
2. Mixing part: The crushed material enters the mixer, which can
quickly and evenly mix the material into the required feed. The
ratio is consistent, and there is no stratification and
precipitation.
Working Principle of Feed Grinder Mixer
The feed grinding mixer is to transport the material to the
grinding device through automatic suction or feeding. The crushed
material enters the mixing barrel, and the rotating motion of the
mixing blade is used to mix the material evenly to ensure balanced
nutrition. There is no need for staff to operate during the
production process, and automatic continuous production is
realized, thereby improving production efficiency and quality.
Advantages of Feed Grinder Mixer
1. Efficient grinder: Equipped with high-speed rotating blades for
fine crushing
2. Uniform grinding: the interior is equipped with a ring screen to
ensure that the particle size after crushing is uniform
3. Adjustable size: blades and sieves can be adjusted in size
according to raw material and feed requirements to achieve
different particle sizes
4. Multifunctional: It can be used in conjunction with other
related equipment to realize continuous production of feed
production line
5. Automatic control: with advanced automatic control system, low
energy consumption and high productivity
Technical Parameters
| Model | 9FH-500 | 9FH-750 | 9FH-1000 | 9FH-1500 | 9FH-2000 |
| Capacity(t/h) | 0.5-1.0 | 0.5-1.0 | 1.0-2.0 | 1.5-2.0 | 1.5-2.0 |
| Power(kw) | 7.5/11kw+2.2kw+1.5kw | 7.5/11kw+2.2kw+1.5kw | 7.5/11kw+3.0kw+1.5kw | 7.5/11kw+4.0kw+1.5kw | 7.5/11kw+5.5kw+1.5kw |
Product Details
1. Grinde
Thickened grinder rotor, dust-free, low noise, can quickly reach
the required particle size.
2. Mixing tank
The capacity is 0.5t, 1t, 2t, 3t, and supports a variety of options
for customization.
3. Internal structure
Equipped with three adjustable elastic drawstrings to make the
stirring shaft rotate in the center to achieve uniform stirring.
4. Pedal discharge port
The feeding is convenient and quick.
